Battery and charging installation shown in our projects
View the existing project photos

Marine Inverter and Inverter/Charger Installation

A marine inverter provides mains power from the boat’s battery bank when shore power is unavailable. We size and fit inverters and Victron inverter/chargers, including the battery cables, protection and connection to the AC installation. Choosing the appliance loads and checking the battery system come before deciding which unit to install.

The presence of a mains socket does not mean every appliance is practical to run from batteries. The inverter converts energy; it does not create it. A useful installation makes clear what can be powered, how that use affects the bank and how the bank will recover its charge afterwards.

Starting with the appliances you intend to use

List the devices that genuinely need mains power away from the berth and identify which may operate together. Some equipment has a start-up demand different from its running demand. That matters when choosing an inverter. Adding up the normal running loads alone is not enough.

Our inverter sizing guide explains how to organise the load information without guessing a capacity. Also consider whether a suitable DC appliance would avoid conversion for a particular task. The aim is a system that supports your use of the boat, not a large unit whose demands exceed the bank and charging available.

An inverter or an inverter with a charger built in

An inverter alone converts battery energy to AC. An inverter/charger also incorporates charging from an appropriate AC input, with the transfer arrangements defined by its design. Those differences affect how it connects to shore power and any other AC source aboard.

Victron equipment may offer useful integration with monitoring and other charging sources, but the exact model and its features matter. Our Victron service covers supply and set-up. A replacement should be checked against the boat’s existing arrangement rather than connected on the assumption that all inverter/chargers behave the same way.

Providing the battery current without unsafe shortcuts

The DC side can carry substantial current even though it operates at battery voltage. Cable sizing, terminations, fusing and isolation therefore deserve serious attention. A unit mounted far from the bank may need a more demanding supply route than one nearby; tidy appearance does not establish suitability.

We look at access for installation and later inspection, as well as protecting the conductors from movement and chafe. Battery terminals must remain protected against accidental contact. An undersized cable or poor joint can overheat, so do not try an inverter on loose temporary leads to find out whether the batteries can run it.

Connecting AC protection and earthing correctly

Plan how the inverter output connects to the boat’s AC system. RCD protection, earthing and neutral arrangements must suit the equipment and the boat’s supply switching. Shore power, inverter and generator sources must not be allowed to meet through an improvised connection. A plug-to-plug lead is not an installation method.

The marine earthing and bonding guide explains the background, but the final arrangement depends on equipment instructions and testing aboard. Mains electricity can give a serious shock. Do not open live distribution equipment or change neutral and earth connections to clear a trip; the reason for the trip needs investigation.

Checking capacity and the path back to a charged bank

Running an inverter reduces the stored energy available to other services. The bank must support the discharge required by the intended loads, and there must be an appropriate way to replenish it. Solar contribution, alternator charging and time connected to shore power all shape that decision.

Lithium can form part of the system, but its management limits and charging design still need checking. A battery disconnect during inverter use is not something to ignore. Monitoring helps make consumption visible, while realistic appliance choices keep expectations grounded in the actual bank rather than the inverter’s headline rating.

Fitting, testing and knowing how to operate it

The installation plan covers mounting, ventilation requirements, cable access and the intended socket or distribution connections. At commissioning, the system is tested in the operating modes it is designed to use, with protection and source switching considered alongside whether an appliance runs.

Send photographs of the battery space, AC panel and existing chargers when enquiring. Include the appliance list and any inverter model already selected. After fitting, make sure you understand isolation, what it can safely run and which settings matter. Keep instructions accessible so later alterations to chargers or AC supplies are checked against the installed design.

Frequently asked questions

Does an inverter charge the batteries as well as powering sockets?

An inverter alone does not. An inverter/charger includes a charging function from a suitable AC input. The chosen model determines the functions and connections available.

Why can an appliance start badly even if its running load looks suitable?

Start-up demand may differ from normal running demand. Selection needs that information as well as the intended simultaneous loads and the battery system’s capability.

Can I feed the boat’s sockets through a lead with plugs at both ends?

No. That is unsafe. Inverter output needs a properly designed connection with appropriate protection and switching so different AC sources cannot be connected together.

Is a larger inverter a substitute for a bigger battery bank?

No. The inverter converts stored energy and still depends on the bank’s discharge capability and capacity. Charging arrangements also need to replace what is used.

What information helps decide where an inverter can be mounted?

Pictures of available space, battery and AC cable routes, plus the equipment instructions, help assess access, support and ventilation requirements before fitting.
